Información Básica.
No. de Modelo.
JF-IR-13Q
cuerpo de la válvula, capó, carrete
nylon reforzado con fibra de vidrio
diafragma
goma
junta
goma
primavera
acero inoxidable
tornillos del capot
acero inoxidable
temperatura adecuada
más alto 60degc/140degf
presión máxima
10bar
calibre opcional tipo y
1/2"-6";DN40-DN150
calibre opcional tipo f
2" 3" 3"L;DN50,DN80,DN80L,DN100
Paquete de Transporte
1pieces/Box
Especificación
Y TYPE
Marca Comercial
BERMAD
Origen
China
Capacidad de Producción
500pieces/Day
Descripción de Producto
Quick Pressure Relief Valve
The BERMAD Model IR-13Q is a hydraulically operated, diaphragm actuated control valve designed to relief excessive line pressure when it rises above the preset maximum. It responds to rises in system pressure immediately, accurately and with high repeatability, by opening fully. The BERMAD Model IR-13Q provides smooth drip tight closing.
PRODUCT FEATURES & BENEFITS
- Hydraulic Control Valve
- Line pressure driven
- Short response time
- Long term drip tight sealing
- Engineered Plastic Valve with Industrial Grade Design
- Adaptable on-site to a wide range of end connection sizes and types
- Highly durable, chemical & cavitation resistant
- hYflow 'Y' Valve Body with "Look Through" Design
- Ultra-high flow capacity at Low pressure loss
- Unitized Flexible Super Travel Diaphragm with a Guided Plug
- Accurate and stable regulation with smooth closing
- Requires low actuation pressure
- Prevents diaphragm erosion and distortion
TYPICAL PRODUCT APPLICATIONS
optional interface
internal thread :BSP-T(1/2"-3"L;DN40-DN80L)
external thread:BSP-F(2"&2 ½";DN50&DN65)
Flange interface:3",3"L,4",4"L,6"R
Clamp interface:2",3",4" Plastic Groove Adapter
OUR PROJECT
For more information and technology support ,please connect us
Bermad is one of our good supplier in china project. Now we are authorized by them to be the distributor in China.We can sale small quantity if you need in your project with other products.
For more informaiton please contact us .
- System Burst Protection
- Momentary Pressure Peak Elimination
- System Failure Visual Indication
- Filter Burst Protection
optional interface
internal thread :BSP-T(1/2"-3"L;DN40-DN80L)
external thread:BSP-F(2"&2 ½";DN50&DN65)
Flange interface:3",3"L,4",4"L,6"R
Clamp interface:2",3",4" Plastic Groove Adapter
The relief pilot [1] is used when the pre-valve pressure [P1] suddenly rises above the pilot setting The valve opens immediately, and when the pressure in front of the valve drops below the set value of the pilot valve, the valve shield. The operation test can be carried out manually using the air vent valve [2].
